Quarter Turn Fastener

Compression Latches

Two versions of our Compression Latches are available with the following features:

Key Features:

• 5.0mm pull up via a cam together with a positive lock location in the closed position gives compression of gaskets and vibration resistance
• Smooth half turn action via the cam means a simple fatigue free action IP65 sealed with an internal seal and a seal under the head
• Anti-vibration locking washer for the fixing nut
• Position indicator for the cam
• Operated by 8.0mm square key

Material:

• Zinc Alloy Chrome Plated housing with Zinc Plated Steel cam and washer. The insert is manufactured from a Zinc Alloy Chrome Plated face and Steel interior and cam

Finishes:

• Other options can be offered including: Alternative head styles, including European railway standard. Cranked cams. Alternative finishes including a completely stainless steel version

Typical Applications:

Suitable for the railway, commercial, construction and agricultural vehicle, air conditioning industries and other applications, subject to vibration or the need to compress gaskets for an effective seal.

Hall-Fast stocks and extensive range of other types of Quarter Turn Fasteners & Locks please follow the link to see the full range
